MikroTik CubeG-5ac60ay, Cube 60Pro ac, 60GHz with 5GHz failover, 1Gbit full duplex up to 2.4km, Quad Core 716MHz, 256MB, 1xGigabit, L4

Long gone are the days when you had to rely on cables for speed and stability. 60 GHz solutions offer fiber-like speed and stability - while saving you plenty of time and money on installation and maintenance. Our latest Cube 60Pro product line is taking the advantages of 60 GHz networking to the next level – with the 802.11ay standard for even higher distances, stability, speed, and convenience.

The Cube 60Pro ac CPE allows you to establish ultra-fast point-to-point connections over distances as far as 1 km. And that’s not all – we have added Channel 5* support, so you can reach even higher distances if necessary. In our tests, the Cube 60Pro ac easily maintained a reliable connection over 2.4 km. Bridging two locations has never been easier!

You can get a preconfigured kit of two Cube 60Pro ac devices: the Wireless Wire Cube Pro. Just point the Cubes at one another and power them on! They will form a blazing fast encrypted wireless connection. Pure plug-and-play!

Forget about downtime with the automatic 5 GHz backup connection

The 60 GHz frequency is unaffected by the crowded wireless spectrum, it offers high speed and capacity. But it can sometimes struggle during bad weather conditions. That’s why both Cube 60Pro devices feature an automatic 5 GHz failover. We have added a powerful directional antenna so that the 5 GHz range can keep up with the 60 GHz.

More durability, less unwanted attention

We have upgraded the enclosure to feature a strong metal base – for better mounting and cooling options. The Cube form-factor emerges from pure practicality: it is durable, unobtrusive, and compact.

Specifications

Details
Product code CubeG-5ac60ay
Architecture ARM 32bit
CPU IPQ-4019
CPU core count 4
CPU nominal frequency auto (448 - 896) MHz
Dimensions 115 x 95 x 82 mm
RouterOS license 4
Operating System RouterOS
Size of RAM 256 MB
Storage size 64 MB
Storage type FLASH
MTBF Approximately 200'000 hours at 25C
Tested ambient temperature -40°C to 70°C


Powering

Details
Number of DC inputs 1 (PoE-IN)
Max power consumption 10 W
Cooling type Passive
PoE in 802.3af/at
PoE in input Voltage 18-48 V

Wireless specifications

Details
Wireless 5 GHz Max data rate 433 Mbit/s
Wireless 5 GHz number of chains 1
Wireless 5 GHz standards 802.11a/n/ac
Antenna gain dBi for 5 GHz 11.5
Wireless 5 GHz chip model IPQ4019
Wireless 5 GHz generation Wi-Fi 5

Ethernet

Details
10/100/1000 Ethernet ports 1

Other

Details
GNSS standards GPS

Certification & Approvals

Details
Certification CE, FCC, IC, EAC, ROHS
IP IP54

Wireless specifications

5 GHz Transmit (dBm) Receive Sensitivity
6MBit/s 22 -93
54MBit/s 18 -74
MCS0 22 -93
MCS7 17 -71
MCS9 15 -68

Included parts


  • 24V 0.8A power adapter

  • Hose clamp 1

  • Cube mount (bracket)

  • Gigabit PoE injector

Ethernet test results

CubeG-5ac60ay IPQ-4019 1G one port test
Mode Configuration 1518 byte 512 byte 64 byte
kpps Mbps kpps Mbps kpps Mbps
Bridging none (fast path) 81,2 986.1 234,9 962.2 1482,6 759.1
Bridging 25 bridge filter rules 81,2 986.1 227,7 932.7 231,9 118.7
Routing none (fast path) 81,2 986.1 235,1 963.0 1421,8 728.0
Routing 25 simple queues 81,2 986.1 235,1 963.0 458,3 234.6
Routing 25 ip filter rules 81,2 986.1 234,9 962.2 236,8 121.2
  1. All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
  2. Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
  3. Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results

The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase..

Part Number:
CubeG-5ac60ay
Supplier:
MikroTik
